GS-065-030-2-L-MR
GS-065-030-2-L-MRManufacturer: Infineon Technologies Canada Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 650 V 30A (Tc) Surface Mount 8-PDFN (8x8)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | GaNFET (Gallium Nitride) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) |
| Rds On (Max) @ Id, Vgs | 68mOhm @ 5.5A, 6V |
| FET Feature | - |
| Power Dissipation (Max) | - |
| Vgs(th) (Max) @ Id | 2.6V @ 7.5mA |
| Supplier Device Package | 8-PDFN (8x8) |
| Grade | - |
| Drive Voltage (Max Rds On, Min Rds On) | 6V |
| Vgs (Max) | +7V, -10V |
| Drain to Source Voltage (Vdss) | 650 V |
| Gate Charge (Qg) (Max) @ Vgs | 6.7 nC @ 6 V |
| Input Capacitance (Ciss) (Max) @ Vds | 235 pF @ 400 V |
| Qualification | - |
Request a Quote
