DS1631U+T&R
SENSOR DIGITAL -55C-125C 8UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Analog and Digital Output
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1631U-T-R is a digital local temperature sensor with a sensing range of -55°C to 125°C. This component features an 11-bit resolution, offering high precision in temperature measurements. The output interface is I2C, facilitating straightforward integration into various system architectures. Key operational features include one-shot conversion, an output switch for threshold monitoring, programmable limit settings, and programmable resolution for application-specific tuning. A standby mode is also available to minimize power consumption. The DS1631U-T-R is supplied in an 8-uMAX/uSOP package, suitable for surface mounting. Its operating temperature range and accuracy specifications (±0.5°C at 0°C to 70°C, ±2°C over the full -55°C to 125°C range) make it suitable for applications in industrial control, consumer electronics, and computing. The device operates from a supply voltage of 2.7V to 5.5V and is provided on a tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | One-Shot, Output Switch, Programmable Limit, Programmable Resolution, Standby Mode |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | I2C |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Sensor Type | Digital, Local |
| Resolution | 11 b |
| Supplier Device Package | 8-uMAX/uSOP |
| Test Condition | 0°C ~ 70°C (-55°C ~ 125°C) |
| Accuracy - Highest (Lowest) | ±0.5°C (±2°C) |
| Sensing Temperature - Local | -55°C ~ 125°C |
| Sensing Temperature - Remote | - |
